PSB-S1 Thermistor
The standard product in PSB thermistors
- Gold electrodes are used on the thermistor chip
- Due to the glass encapsulation, excellent heat resistance and weather resistance are ensured
- Ensure long-term stability of resistance
- Using consistent automated production, mass production and supply of high-quality products
- Achievements in obtaining patents in 8 major countries in the world (Japan, the United States, Canada, France, the United Kingdom, Germany, Italy, and Switzerland)
Features
| Application example |
Outside the following fields, it is suitable for equipment with high reliability requirements for temperature detection and control
|
|---|---|
| range of working temperature | -50～+300℃ |
| Thermal time constant | About 12 seconds |
| Dissipation constant | About 1.3mW/℃ |
| Insulation resistance | DC500V 50MΩ or more |
※When there is no special description, the thermal time constant and dissipation constant are the test results in still air.
Voltage-current characteristics
